Key Features：
●
High-performance Intel® Core™ processors (6th–9th Gen) with flexible chipset
options.
● Fanless sealed chassis for silent and reliable operation.
● Multiple video outputs (VGA, DVI-D, HDMI) supporting diverse
display setups.
● Wide voltage input (12–55V) for industrial power environments.
● Rugged design with extended temperature, vibration and shock
tolerance.
● Expandable I/O including PCI/PCIe slots, GPIO, COM and USB.
More About This Product：
| Category |
Specification |
| CPU |
Intel® Core™ i9/i7/i5/i3, Pentium®, Celeron®
(LGA1151,
6th–9th Gen)
Coffee Lake (8/9th Gen), Kaby Lake (7th Gen), Skylake (6th Gen) |
| Chipset |
Intel® H110 / Q170 |
| Memory |
2 × DDR4 2133/2400/2666MHz DIMM, up to 64GB
|
| Display |
1 × VGA, 1 × DVI-D, 1 × HDMI |
| Networking |
2 × Intel® i210AT, 1 × Intel® i219LM |
| Storage |
1 × mSATA, 1 × M.2 M-Key (2280, SATA/NVMe x4, Q170
only)
2.5" or 3.5" HDD/SSD (optional) |
| RAID |
0/1 (Q170) |
| USB |
6 × USB 3.0 (expandable) |
| COM |
2 × COM (expandable; TTL/RS232/422/485; optional
isolation) |
| GPIO |
16 or 32 channels; standard or opto-isolated rugged
GPIO; NPN/PNP selectable; up to 80V withstand |
| Expansion Slots |
1 × mini-PCIe (full-size): WiFi/4G/MVB/custom
modules
1 × M.2 B-Key 3042/3052: 4G/5G modules
PCIe: x16, x4 (Q170), x1; PCI legacy options |
| Audio |
Realtek codec, Line-out, Mic-in |
| Watchdog |
1–255 sec system reset |
| Power Input |
12V, 19V, 24V, 36V, 48V, 55V (selectable); lockable
connectors |
| Operating Systems |
Windows 7/10/11, Linux distributions, China OS
(Kylin,
etc.) |
| Cooling |
Fanless sealed chassis, optional
temperature-controlled
external fan |
| Mounting |
Horizontal or vertical (multi-slot versions) |
| Environmental |
Operating: -10℃ ~ 60℃; Storage: -20℃ ~ 85℃
Humidity: 5% ~ 95% (non-condensing)
Vibration (SSD): 5Grms; (HDD): 1Grms
Shock (SSD): 50G / 11ms; (HDD): 20G / 11ms |
| Certifications |
CE, FCC, CCC |
